Robust Live Center

Robust Live Centers use bigger bearings, and warrants them for five years.

A precision 40 degree angular contact ball
bearing, sealed & lubricated for life, carries both the thrust load and rear radial load.

Combined with a precision radial bearing in the nose, this two bearing setup will deliver long lasting service and accuracy.

Robust Live Center Bearing

The tip of the center extends and reverses to accomodate your turning.

The flat end is useful when reverse chucking using a vacuum chuck or jam chuck. The center will support the work without marking the bottom of the piece.

The cup center is threaded 3/4‐10 for standard accessories.

A 5/16” thru hole accomodates drilling.

#2 Morse Taper shank is tapped 3/8-16 for drawbar applications.

The center body and shank are plated for corrosion resistance.

 Live Center REversed

Live Center Normal

Live Center Drawing





















Optional
Aluminum Tip
and Reversible
4" Bull Nose Set

Fits other manufacturer's centers with 3/4-10 threads.

With Cone - 400 with cone reversed - 400 With Tip - 400
